High Voltage Magnetics
Design Examples:

Pulse Transformer

  • Input Voltage: 11,700V Pulse

  • Output Voltage: 117kV Pulse

  • Freqency: 250pps

  • Duty Cycle: 0.192%

  • Application: Ground based radar


Flyback Transformer

  • Input Voltage: 285Vpk

  • Output Voltage: 60kVp-p

  • Dimensions: 11.6"H x 13.5"W x 6.5"L

  • Application: Medical oncology




Three Phase Power Transformer

  • Input: 208VAC, 550Vwkg

  • Output: 9,720VAC @ 1.45A, 14,300Vwkg

  • Dimensions: 16.8"W x 7.56H x 5.34"D

  • Application: Doppler (weather) radar


Precision Magnetics

  • Voltage: 200kV

  • Current: 2000A

  • Ratings: to 200kVA



Manufacturers:





| | | | | |
