High Power Filters



Filtron Catalog


Power Line EMI/EMC/HEMP Facility Filter

  • Voltage range: 12VDC-5500VAC

  • Current: 1-5000A

  • Frequency: 50-400Hz

  • Attenuation: 120dB from 9KHz to 18GHz

  • Application: Shielded rooms, secure facilities


      Power Line Filters (M15733)

  • Voltage range: 0-277VAC line-neutral,  0-480V  line-line, 600VDC MAX

  • Current: 5-200A

  • Frequency: DC-400Hz

  • Maximum Voltage Drop: 2%

  • Bleeder discharge resistors

  • Overload: 140% rated current 15 min.

  • Attenuation: 100dB (14KHz to 10GHz)


Power Line Filters

  • Voltage:  5kV line-to-line

  • Current: 370A

  • Frequency: 50Hz

  • Insertion Loss: 80dB @ 1GHz

  • Dimensions: 5"H x 6"W x 30"D

  • Application: Facility power filter
